Saddles supplied without preconfigured string grooves allowing for individual string spacing

Saddles are from brass

Slant angle to be determined by guitarmaker based on scale length and string gauge.

Installation:

non-reverse

: intonations screws show to the pickups

reverse

: intonations screws show to the tailpiece

(*Les Paul is a protected trademark owned by Gibson Musical Instruments Corporation).

technical specification

distance height adjustment screws 74 - 74,5mm, string spacing E-e 52,5mm, string radius 12“-14“ (usable for fretboard max. 10-16 inch, depending on the notches of the string saddles more outside or inside), minimal G/d string height above body 13,7mm, weight 53g (70g with accessories), for lefty: yes

scope of supply

2 press-in bushings M7 with 2 height-adjustment screws M5 (metric).

For other press-in bushings and height-adjustment screws please see under Bridges/ Replacement Kits and order additionally.
